Supercharge Silverplus SMF77H
SMF77H
Nominal Voltage:
12V
Size:
N77H
CCA @(-18°C):
820
RC @ 25A:
170
Ah 20hr:
95
Length:
315mm
Width:
175mm
Height:
190mm
Total Height:
190mm
Battery Type:
Maintenance Free
Technology:
SMF CAL
Ledge:
EL & FL
Accessibility:
TS
Hydro:
YES
Post Style:
STD
Assembly:
C
Warranty Priv:
36 mths
Warranty Comm:
18 mths
Abbreviations and Battery Assemblies
![$specification_and_dimension['abbreviation_image']['alt']](https://www.supercharge.com.au/wp-content/uploads/2025/02/WEBP-Battery-Assembly.webp)
![$specification_and_dimension['abbreviation_image_two']['alt']](https://www.supercharge.com.au/wp-content/uploads/2025/02/WEBP-Transparent-Image.webp)
AP:
Automotive Post
CT:
Centered Terminal
CV:
Central Venting
DFA:
Dual Fit Aligned Terminals
DFP:
Dual Fit Parallel Terminals
DST:
Dual System Terminals
DT:
Automotive Post & Stud
DWNT:
Dual Wingnut
EL:
End Ledge
ELPT:
Embedded Low Profile
EUTR:
Embedded Universal/Reverse
F1:
F1 Terminal
F1-F2:
F1/F2 Terminal
F10:
F10 Terminal
F10M8:
F1 Terminal (1.25mmx15mm Stud I))
F11:
F11 Terminal
F11M6:
F11 Terminal (6mm/8mm Insert)
F12:
F12 Terminal
F12M8:
F12 Terminal (1.25mmx15mm Stud I)
F13:
F13 Terminal
F14:
F14 Terminal
F14M8:
F14 Terminal (1.25mmx15mm Stud I)
F18:
F18 Terminal
F2:
F2 Terminal
F22:
F22 Terminal
F3:
F3 Terminal
F3W:
F3W Terminal
F5:
F5 Terminal
F8:
F8 Terminal
F9:
F9 Terminal
FDH:
Fold Down Handles
FL:
Front Ledge
HE:
Hydrometer Eye
M6:
M6
M8:
1.25mmx15mm Stud I
M8-DT:
Automotive Post & Stud (1.25mmx15mm Stud I)
OLT:
Offset Lug Terminal
PT:
Pencil Terminal
RPH:
Rope Handles
RT:
Recessed Terminal
RTH:
Retractable Handles
ST:
Side Terminal
STD:
Standard Terminal
T1:
T1
T11:
T11
T12:
T12
T2:
T2
T6:
T6
T6A:
T6A
TM:
Twin Marine Terminal - Type M
TS:
Top Stud Terminal
UT:
Universal
WNT:
Wingnut
SMF77H
Nominal Voltage:
12V
Size:
N77H
CCA @(-18°C):
820
RC @ 25A:
170
AH(20hr):
95
Length:
315mm
Width:
175mm
Height:
190mm
Total Height:
190mm
Battery Type:
Maintenance Free
Technology:
SMF CAL
Accessibility:
TS
Post Style:
STD
Assembly:
C
Hydro:
YES
Ledge:
EL & FL
Warranty Comm:
18mths
Warranty Priv:
36mths
Abbreviations and Battery Assemblies
AP: Automotive Post
CV: Central Venting
CT: Centered Terminal
DFA: Dual Fit Aligned Terminals
DFP: Dual Fit Parallel Terminals
DST: Dual System Terminals
DT: Automotive Post & Stud
DWNT: Dual Wingnut
EL: End Ledge
ELPT: Embedded Low Profile
EUTR: Embedded Universal/Reverse
F1: F1 Terminal
F1-F2: F1/F2 Terminal
F2: F2 Terminal
F3: F3 Terminal
F3W: F3W Terminal
F5: F5 Terminal
F8: F8 Terminal
F9: F9 Terminal
F10: F10 Terminal
F10M8: F1 Terminal (1.25mmx15mm Stud I))
F11: F11 Terminal
F11M6: F11 Terminal (6mm/8mm Insert)
F12: F12 Terminal
F12M8: F12 Terminal (1.25mmx15mm Stud I)
F13: F13 Terminal
F14: F14 Terminal
F14M8: F14 Terminal (1.25mmx15mm Stud I)
F18: F18 Terminal
F22: F22 Terminal
F3: F3 Terminal
F5: F5 Terminal
F9: F9 Terminal
FL: Front Ledge
FDH: Fold Down Handles
HE: Hydrometer Eye
M6: M6
M8: 1.25mmx15mm Stud I
M8-DT: Automotive Post & Stud (1.25mmx15mm Stud I)
OLT: Offset Lug Terminal
PT: Pencil Terminal
RT: Recessed Terminal
RPH: Rope Handles
RTH: Retractable Handles
STD: Standard Terminal
ST: Side Terminal
TS: Top Stud Terminal
UT: Universal
WNT: Wingnut
SMF77H
SMF77H is built with Lead-Calcium Tropicalised Power Plates, assembled using hardened alloys and intercell connections. This fully-sealed, maintenance-free battery ensures high-efficiency electrical flow design. Formulated with high-purity lead and electrolyte, it is designed for European Automotive Applications.
ooking for the best car battery? Read our guide on Supercharge Superguide to Car Batteries for expert advice!
Register your battery now and keep your investment safe for years to come!
| MAKE | MODEL |
| ALFA ROMEO | 159 |
| AUDI | A3 |
| AUDI | A4 |
| AUDI | A5 |
| AUDI | A6 |
| AUDI | RS4 |
| AUDI | TT |
| AUDI | TTS |
| BMW | 118D |
| CHRYSLER | 300 |
| DODGE | NITRO |
| FORD | EVEREST |
| FORD | RANGER |
| HOLDEN | CRUZE |
| HYUNDAI | PALISADE |
| HYUNDAI | SANTA FE |
| KIA | CARNIVAL |
| KIA | SORENTO |
| KIA | SPORTAGE |
| KIA | STINGER |
| LDV | G10 |
| MAZDA | BT50 |
| MERCEDES BENZ | C200 |
| MERCEDES BENZ | C320 |
| PORSCHE | 911 |
| RENAULT | LAGUNA |
| RENAULT | LATITUDE |
| TOYOTA | LANDCRUISER |
